Magnetic Fractals

(type=magnet1m/.../magnet2j)

These fractals use formulae derived from the study of hierarchical lattices, in the context of magnetic renormalisation transformations. This kinda stuff is useful in an area of theoretical physics that deals with magnetic phase-transitions (predicting at which temperatures a given substance will be magnetic, or nonmagnetic). In an attempt to clarify the results obtained for Real temperatures (the kind that you and I can feel), the study moved into the realm of Complex Numbers, aiming to spot Real phase-transitions by finding the intersections of lines representing Complex phase-transitions with the Real Axis. The first people to try this were two physicists called Yang and Lee, who found the situation a bit more complex than first expected, as the phase boundaries for Complex temperatures are (surprise!) fractals. And that's all the technical (?) background you're getting here! For more details (are you SERIOUS ?!) read "The Beauty of Fractals". When you understand it all, you might like to rewrite this section, before you start your new job as a professor of theoretical physics... In Fractint terms, the important bits of the above are "Fractals", "Complex Numbers", "Formulae", and "The Beauty of Fractals". Lifting the Formulae straight out of the Book and iterating them over the Complex plane (just like the Mandelbrot set) produces Fractals. The formulae are a bit more complicated than the Z^2+C used for the Mandelbrot Set, that's all. They are :

 [ ] 2 | Z^2 + (C-1) | Magnet1 : | ---------------- | | 2*Z + (C-2) | [ ]

 [ ] 2 | Z^3 + 3*(C-1)*Z + (C-1)*(C-2) | Magnet2 : | -------------------------------------------------- | | 3*(Z^2) + 3*(C-2)*Z + (C-1)*(C-2) + 1 | [ ]

These aren't quite as horrific as they look (oh yeah ?!) as they only involve two variables (Z and C), but cubing things, doing division, and eventually squaring the result (all in Complex Numbers) don't exactly spell S-p-e-e-d ! These are NOT the fastest fractals in Fractint ! As you might expect, for both formulae there is a single related Mandelbrot-type set (magnet1m, magnet2m) and an infinite number of related Julia-type sets (magnet1j, magnet2j), with the usual toggle between the corresponding Ms and Js via the spacebar. If you fancy delving into the Julia-types by hand, you will be prompted for the Real and Imaginary parts of the parameter denoted by C. The result is symmetrical about the Real axis (and therefore the initial image gets drawn in half the usual time) if you specify a value of Zero for the Imaginary part of C. Fractint Historical Note: Another complication (besides the formulae) in implementing these fractal types was that they all have a finite attractor (1.0 + 0.0i), as well as the usual one (Infinity). This fact spurred the development of Finite Attractor logic in Fractint. Without this code you can still generate these fractals, but you usually end up with a pretty boring image that is mostly deep blue "lake", courtesy of Fractint's standard Periodicity Logic . See Finite Attractors for more information on this aspect of Fractint internals.

(Thanks to Kevin Allen for Magnetic type documentation above).
(Taken from the Fractint manual, available for those of you with Scribd at https://www.scribd.com/document/71504518/FRACTINT)
